| 5W ~ 300W Level VI
ITE Adapter Series |
|
| All models with 90
~ 264Vac Input and Compact Size & Competitive Pricing |
|
KEY FEATURES
* Low Standby Power Consumption
* Energy Star Level VI
* CoC V5 Tier 2 (2016)
* Class I & II Construction
* Up to 5,000M Operating Altitudet
* Lithium-ion Battery Charger Option with LED Indicator
* 3 Years Warranty |
|
|
| Single Output
Series and all CB IEC62368-1 Compliance |
|
| Model No. |
Watt |
Size (mm)
L × W × H |
Output
Voltage |
Standby
Power (Watt) |
UL
approved to |
Features |
|
| UES06WZ-SPA |
6 |
73.5 × 42.5 × 30.7 |
4.2 ~ 12 |
<0.075 |
ES60601-1
UL60950-1 |
Interchangeable AC Plugs
Class II Isolation
Optional USB2.0 port (5V only) |
|
| UES12LZ-SPA |
12 |
62 × 29 × 40 |
12 |
<0.075 |
UL62368-1 |
Interchangeable AC Plugs
Class II Isolation
4KV Surge Immunity |
|
| UES12LCP-SPA |
12 |
76 × 30.3 × 48.2 |
4 ~ 24 |
<0.075 |
ES60601-1
UL60950-1 |
Interchangeable AC Plugs
Class II Isolation
Optional Lithium battery charger |
|
| UES18LZ-SPA |
18 |
70 × 30 × 43.5 |
12 |
<0.075 |
UL62368-1 |
Interchangeable AC Plugs
Class II Isolation
4KV Surge Immunity
No Y-Capacitor Design |
|
| UES18LCP-SPA |
18 |
88 × 30 × 57 |
5 ~ 24 |
<0.075 |
ES60601-1
UL60950-1 |
Interchangeable AC Plugs
Class II Isolation |
|
| UES24WZ-SPA |
24 |
85 × 51 × 28 |
12 |
<0.075 |
UL62368-1 |
Interchangeable AC Plugs
Class II Isolation
6KV Surge Immunity |
|
| UES24LCP-SPA |
24 |
88 × 30 × 57 |
6.1 ~ 52 |
<0.075 |
ES60601-1
UL60950-1
UL62368-1 |
Interchangeable AC Plugs
Class II Isolation |
|
| UES36WZ-SPA |
36 |
85 × 51 × 28 |
12 |
<0.075 |
UL62368-1 |
Interchangeable AC Plugs
Class II Isolation
6KV Surge Immunity |
|
| UES36LCP-SPA |
36 |
97 × 33 × 51 |
9 ~ 36 |
<0.075 |
ES60601-1
UL60950-1 |
Interchangeable AC Plugs
Class II Isolation |
|
| UES36-SPA |
36 |
102 × 50 × 33.5 |
9 ~ 36 |
<0.075 |
ES60601-1
UL60950-1
UL62368-1 |
AC Inlet C8
Class II Isolation |
|
| UES48-SPA |
48 |
122 × 51 × 31.5 |
9.1 ~ 54 |
<0.075 |
ES60601-1
UL60950-1
UL62368-1 |
4 Types of AC Inlet
Class I & II Isolation
4KV Surge Immunity |
|
| UES65-SPAZ |
65 |
125 × 62 × 34 |
9 ~ 54 |
<0.15 |
ES60601-1
UL60950-1
UL62368-1 |
4 Types of AC Inlet
Class I & II Isolation
4KV Surge Immunity |
|
| UES90-SPAZ |
90 |
146 × 59.5 × 36 |
12 ~ 52 |
<0.15 |
ES60601-1
UL60950-1
UL62368-1 |
4 Types of AC Inlet
Class I & II Isolation |
|
|
