6W ~ 90W Level VI ITE Adapter Series
All models with 90 ~ 264Vac Input and Compact Size & Competitive Pricing
KEY FEATURES * Low Standby Power Consumption * Energy Star Level VI * CoC V5 Tier 2 (2016) * Class I & II Construction * Up to 5,000M Operating Altitudet * Lithium-ion Battery Charger Option with LED Indicator * 3 Years Warranty
Single Output Series and all CB IEC62368-1 Compliance
Model No.	Watt	Size (mm) L × W × H		Output Voltage	Standby Power (Watt)	UL approved to	Features
UES06WZ-SPA	6	73.5 × 42.5 × 30.7		4.2 ~ 12	<0.075	ES60601-1 UL60950-1	Interchangeable AC Plugs Class II Isolation Optional USB2.0 port (5V only)
UES12LZ-SPA	12	62 × 29 × 40		12	<0.075	UL62368-1	Interchangeable AC Plugs Class II Isolation 4KV Surge Immunity
UES12LCP-SPA	12	76 × 30.3 × 48.2		4 ~ 24	<0.075	ES60601-1 UL60950-1	Interchangeable AC Plugs Class II Isolation Optional Lithium battery charger
UES18LZ-SPA	18	70 × 30 × 43.5		12	<0.075	UL62368-1	Interchangeable AC Plugs Class II Isolation 4KV Surge Immunity No Y-Capacitor Design
UES18LCP-SPA	18	88 × 30 × 57		5 ~ 24	<0.075	ES60601-1 UL60950-1	Interchangeable AC Plugs Class II Isolation
UES24WZ-SPA	24	85 × 51 × 28		12	<0.075	UL62368-1	Interchangeable AC Plugs Class II Isolation 6KV Surge Immunity
UES24LCP-SPA	24	88 × 30 × 57		6.1 ~ 52	<0.075	ES60601-1 UL60950-1 UL62368-1	Interchangeable AC Plugs Class II Isolation
UES36WZ-SPA	36	85 × 51 × 28		12	<0.075	UL62368-1	Interchangeable AC Plugs Class II Isolation 6KV Surge Immunity
UES36LCP-SPA	36	97 × 33 × 51		9 ~ 36	<0.075	ES60601-1 UL60950-1	Interchangeable AC Plugs Class II Isolation
UES36-SPA	36	102 × 50 × 33.5		9 ~ 36	<0.075	ES60601-1 UL60950-1 UL62368-1	AC Inlet C8 Class II Isolation
UES48-SPA	48	122 × 51 × 31.5		9.1 ~ 54	<0.075	ES60601-1 UL60950-1 UL62368-1	4 Types of AC Inlet Class I & II Isolation 4KV Surge Immunity
UES65-SPAZ	65	125 × 62 × 34		9 ~ 54	<0.15	ES60601-1 UL60950-1 UL62368-1	4 Types of AC Inlet Class I & II Isolation 4KV Surge Immunity
UES90-SPAZ	90	146 × 59.5 × 36		12 ~ 52	<0.15	ES60601-1 UL60950-1 UL62368-1	4 Types of AC Inlet Class I & II Isolation
